You are here: home > Control Equipment > Pneumatic Angle Seat Valve > 2/2 way piston-operated angle-seat valves for netral and aggressive liquids and gases
|
NINGBO SUPERMECH PNEUMATIC HYDRAULIC CO., LTD.
China angle valve manufacturer |
angle valve
| Product Name: | 2/2 way piston-operated angle-seat valves for netral and aggressive liquids and gases |
| Model No.: | JZF |
| Place of Origin: | Zhejiang,China (Mainland) |
| Power: | Solenoid |
| Standard or Nonstandard: | Standard |
| Pressure: | Low Pressure |
| Structure: | Angle |
| Material: | Stainless Steel |
| Temperature of Media: | Normal Temperature |
| Media: | Gas |
| Brand Name: | CCHY |
|
 Add to Basket
|
angle valve Description
Payment & Shipping Terms:
Unit Price:FOB 10.0~50.0 USD
Payment Term:
L/C, D/P, T/T
MOQ: 5 Set/Sets
Means of Transport:Ocean
Supply Capacity:
Production Capacity: 10000Sets/month
Packing: Cartons/Pallets
Delivery Date: The advance payment after15-30days
product name: 2 way 2 piston-operated angle-seat valves for neutral and aggressive liquids and gases
Model: JZF
INSTALLATION & MAINTENANCE
1.Clean the pipes carefully from any residue, dribble or welding residue , to avoid any damage to the seal.
1.Clean the pipes carefully from any residue, dribble or welding residue , to avoid any damage to the seal.
1.To be installed as required, preferably with actuator in upright position
2. 3 connect the pipes according to the reference points (flow direction) found on the valve body . only disassemble the actuator if required by customer.
3.Before taking the valve apart, depressurize the media supply and pilot air supply piping system.
NOTICE:
NOTICE:
Flow direction below the seat (direction A)
1.Valves with flow direction below the seat (direction A) ensure long service life.
2.Valves used for liquid media are water hammer-free.
3.Valves with orifice DN15/DN20/DN25 are ideal for the operating pressure of 0.3Mpa.
Valve with orifice DN32/DN40 are operated with double-acting actuators DN100.
Valve with orifice DN50 are operated with double-acting actuators DN125.
FLOW DIRECTION ABOVE THE SEAT (DIRECTION B)
Valves with direction B provide high sealing integrity, used for steam and gases media. There is a danger of water hammer, when the valves used for liquid media.
We are China angle valve manufacturer offer best angle valve OEM, ODM,service.
View more products of 2/2 way piston-operated angle-seat valves for netral and aggressive liquids and gases, you can click
angle valve
to have a try or contact us via E-mail.
